Technic Parameters

Name

Unit

Specification

Rated Occupant

Person

1

Overall dimension(L*W*H)

mm

4400*1450*2050（±1%）

Ground clearance

mm

150

wheelbase

mm

2130（±1%）

Suction tank volume

m³

1.4-1.6

Suction tank thickness

mm

5

Curb weight

kg

1400（±2%）

Max.speed

km/h

≤30

Power

W

5500

Rated voltage

V

72

Capacity

Ah

165

Charging time

h

6-8
